优势：
纸杯机的工作原理是由主电机带动整机工作，实现链条与凸轮结构的完美结合。
现在的机器用一块铝板代替了以前的三块板的机器，这样机器的故障率大大降低，操作者的培训时间也减少了。
3-9oz单、双膜纸杯可根据客户要求定做。
是一种全自动纸杯成型设备，纸杯由排纸、自动回纸装置（保证准确）、超声波焊接、机械转膜、喷油、打底、打底、预热、滚花、连续卸杯等工艺可稳定生产各种规格的纸杯，是我公司自主研发的通过综合技术改进提高机器性能稳定的造纸设备。
规范：
|
Model
|
Paper Cup Machine
|
|
Cup Side Welding:
|
Ultrasonic
heater
|
|
Paper Cup Size
|
3
~9OZ (30ml~330ml Mould exchangeable)
Max
Cup height to 120 MM
|
|
Raw Material
|
180-350g One or Two side PE coated
Paper180-350g（Popular for Hot and
Cold drink Cups）
|
|
Suitable Paper Weight
|
160—350gsm
|
|
Speed
|
70-90pcs个/min分
|
|
Total Power
|
7.8KW
|
|
Power Source
|
50/60HZ,
380V/220V ( better use 380V, 3 Phase )
|
|
N.W
|
1700Kg
|
|
Gross Weight
|
1800Kg
|
|
Machine Size(L * W * H)
|
2000*900*1600mm
|
|
Package Size(L * W * H)
|
21050*1100*1750mm
|
|
Working Air Source:
|
Air pressure:0.4Mpa;
Air Out-put:0.6m³/minute
Need to buy Air Compressor(by user)
|
|
Cup Bottom Heating:
|
1side PE paper
by heater knurling;
2side PE paper
by cool device knurling
|
|
Cup Bottom Knurling:
|
Heater
Knurling
(if use single
PE coated paper)
|
|
Packing Method
|
Seaworthy
Wooden Case
|
