1.Using Willon touch screen man-machine interface, the operation function is clear at a glance, easy to control
2.Adopt the Japanese original Mitsubishi motion controller, through the integration with the optical fiber, operation stability
3.Japanese Mitsubishi servo motor with German Schick color standard eye correction, accurate tracking printing bag size
4.The raw material loading and unloading adopts hydraulic dynamic lifting structure, and the unwinding adopts automatic constant tension control.
5.The raw material correction adopts brushless servo motor to reduce the adjustment time of paper roll alignment.
|
机器型号 Model |
XL-FD220T |
|
纸袋裁切长度 Cutting Length |
190-430mm |
|
纸袋裁切长度（全）Cutting Length（with handle） |
190-350mm |
|
纸袋宽度 Paper Bag Width |
80-220mm |
|
纸袋宽度（全）Paper Bag Width（with handle） |
120-220mm |
|
袋底宽度Bottom Width |
50-110mm |
|
纸袋克重 paper weight |
60-150g/㎡ |
|
纸袋克重（全）Paper weight（with handle） |
70-140g/㎡ |
|
纸卷宽度 paper roll Width |
370-770mm |
|
纸卷宽度（全）paper roll Width（with handle） |
410-770mm |
|
纸料直径 Paper roll Diameter |
1300mm |
|
纸芯内径 Paper Core Inner Diameter |
76mm |
|
手把贴片长度Handle Patch length |
90mm |
|
手把贴片宽度Handle Patch Width |
50mm |
|
纸绳间距Paper Rope Spacing |
57mm |
|
手把纸绳直径Paper Handle Rope Diameter |
3-5mm |
|
手把贴片纸卷宽度Handle Patch Paper Roll Width |
100mm |
|
手把纸卷直径 Handle Paper Roll Diameter |
1200mm |
|
手把贴片纸克重 Handle Patch Paper Weight |
100-135g/㎡ |
|
机械速度 Mechanical Speed |
30-200pcs/min |
|
纸袋速度 Paper Bag Production Speed |
30-180pcs/min |
|
带手提速度 machine with Handle Speed |
30-180pcs/min |
|
裁切刀具方式 Cutter Method |
锯齿裁切Pinking |
|
总机功率 Total Power |
380V/ 3Phase 4Line 41.5kw |
|
整机气压The whole machine pressure |
0.5-0.8MPa |
|
整机重量 Total Weight |
13000Kg |
|
整机尺寸 Machine Overall Dimension |
11000*4400*1800mm |
|
机器型号 Model |
XL-FD350T |
|
纸袋裁切长度 Cutting Length |
270-530mm |
|
纸袋裁切长度（全）Cutting Length（total） |
270-430mm |
|
纸袋宽度 Paper Bag Width |
120-330mm |
|
纸袋宽度（全）Paper Bag Width（total） |
200-330mm |
|
袋底宽度Bottom Width |
60-180mm |
|
纸袋克重 Paper gsm |
60-150g/㎡ |
|
纸袋克重（全）Paper gsm（total） |
80-150g/㎡ |
|
纸卷宽度 Material Width |
380-1050mm |
|
纸卷宽度（全）Material Width（total） |
570-1050mm |
|
纸料直径 Paper Material Diameter |
1300mm |
|
纸芯内径 Paper Core Inner Diameter |
76mm |
|
手把贴片长度 Handle Patch Length |
152.4mm |
|
手把贴片宽度Handle Patch Width |
50mm |
|
纸绳间距Paper Rope Spacing |
75mm |
|
手把纸绳直径Paper Handle Rope Diameter |
3-5mm |
|
手把贴片纸卷宽度Handle Patch Paper Roll Width |
100mm |
|
手把纸卷直径 Handle Paper Roll Diameter |
1200mm |
|
手把贴片纸克重 Handle Patch Paper Weight |
100-135g/㎡ |
|
机械速度 Mechanical Speed |
30-200pcs/min |
|
纸袋速度 Paper Bag Production Speed |
30-180pcs/min |
|
带手提速度 Handle Speed |
30-150pcs/min |
|
裁切刀具方式 Cutter Method |
锯齿裁切Pinking |
|
总机功率 Total Power |
380V/ 3Phase 4Line 41.5kw |
|
整机气压The whole machine pressure |
0.5-0.8MPa |
|
整机重量 Total Weight |
15000Kg |
|
整机尺寸 Machine Overall Dimension |
14000*6000*2400mm |
|
机器型号 Model |
XL-FD450T |
|
纸袋裁切长度 Cutting Length |
270-530mm |
|
纸袋裁切长度（全）Cutting Length（total） |
270-430mm |
|
纸袋宽度 Paper Bag Width |
220-430mm |
|
纸袋宽度（全）Paper Bag Width（total） |
220-430mm |
|
袋底宽度Bottom Width |
90-180mm |
|
纸袋克重 Paper gsm |
80-150g/㎡ |
|
纸袋克重（全）Paper gsm（total） |
80-150g/㎡ |
|
纸卷宽度 Material Width |
650-1290mm |
|
纸卷宽度（全）Material Width（total） |
690-1290mm |
|
纸料直径 Paper Material Diameter |
1200mm |
|
纸芯内径 Paper Core Inner Diameter |
76mm |
|
手把贴片长度 Handle Patch Length |
190.5mm |
|
手把贴片宽度Handle Patch Width |
50mm |
|
纸绳间距Paper Rope Spacing |
95mm |
|
手把纸绳直径Paper Handle Rope Diameter |
3-5mm |
|
手把贴片纸卷宽度Handle Patch Paper Roll Width |
100mm |
|
手把纸卷直径 Handle Paper Roll Diameter |
1200mm |
|
手把贴片纸克重 Handle Patch Paper Weight |
100-135g/㎡ |
|
机械速度 Mechanical Speed |
30-180pcs/min |
|
纸袋速度 Paper Bag Production Speed |
30-150pcsmin |
|
带手提速度 Handle Speed |
30-130pcs/min |
|
裁切刀具方式 Cutter Method |
锯齿裁切Pinking |
|
总机功率 Total Power |
380V/ 3Phase 4Line 41.5kw |
|
整机气压The whole machine pressure |
0.6-0.7MPa |
|
整机重量 Total Weight |
15500Kg |
|
整机尺寸 Machine Overall Dimension |
14000*6000*2400mm |
