1.Using Willon touch screen man-machine interface, the operation function is clear at a glance, easy to control
2.Adopt the Japanese original Mitsubishi motion controller, through the integration with the optical fiber, operation stability
3.Japanese Mitsubishi servo motor with German Schick color standard eye correction, accurate tracking printing bag size
4.The raw material loading and unloading adopts hydraulic dynamic lifting structure, and the unwinding adopts automatic constant tension control.
5. The raw material correction adopts servo motor to reduce the adjustment time of paper roll alignment.
|
Model |
XL-FD220 |
|
|
Paper bag length(C) |
190-430mm |
|
|
Paper bag width(W) |
80-220mm |
|
|
Paper bag bottom width(H) |
50-110mm |
|
|
Paper thickness |
50-150g/㎡ |
|
|
Paper bag speed |
30-200 pcs/min |
|
|
Paper roll width |
290-710mm |
|
|
Roll paper diameter |
Φ1300mm |
|
|
Inner diameter of paper |
Φ76mm |
|
|
Machine power |
3 phases 4 wires 380V 15kw |
|
|
Machine weight |
6000kg |
|
|
Machine size |
8200x3500x2200mm |
|
Model |
XL-FD330 |
|
|
Paper bag length(C) |
||
|
Paper bag width(W) |
120-330mm |
|
|
Paper bag bottom width(H) |
60-180mm |
|
|
Paper thickness |
60-150g/㎡ |
|
|
Paper bag speed |
30-180 pcs/min |
|
|
Paper roll width |
380-1050mm |
|
|
Roll paper diameter |
Φ1300mm |
|
|
Inner diameter of paper |
Φ76mm |
|
|
Machine power |
3 phases 4 wires 380V 15kw |
|
|
Machine weight |
8500kg |
|
|
Machine size |
10000x3700x2200mm |
|
Model |
XL-FD450 |
|
|
Paper bag length(C) |
270-530mm |
|
|
Paper bag width(W) |
220-430mm |
|
|
Paper bag bottom width(H) |
90-180mm |
|
|
Paper thickness |
80-150g/㎡ |
|
|
Paper bag speed |
30-150 pcs/min |
|
|
Paper roll width |
660-1290mm |
|
|
Roll paper diameter |
Φ1300mm |
|
|
Inner diameter of paper |
Φ76mm |
|
|
Machine power |
3 phases 4 wires 380V 15kw |
|
|
Machine pressure |
0.5mpa-0.8mpa |
|
|
Machine weight |
9000kg |
|
|
Machine size |
10000x3800x2200mm |
