1 The man-machine interface of Weilun touch screen is adopted, the operation function is clear at a glance, easy to control
2 Adopt the Japanese original Mitsubishi motion controller, through the integration with the optical fiber, operation stability
3 Japanese Mitsubishi servo motor with German Sick color standard eye correction, accurate tracking printing bag size
4 The loading and unloading of raw material adopts hydraulic dynamic lifting structure, and the unwinding adopts automatic constant tension control
5 Brushless servo motor is used to correct the deviation of raw material and reduce the adjustment time of paper roll alignment
|
机型 |
XL-JD260 |
XL-JD350 |
|
纸袋速度 machine speed |
100-600pcs/min |
30-400pcs/min |
|
切袋长度cutting length |
120-400mm |
200-650mm |
|
制袋长度 bag length |
100-380mm |
180-630mm |
|
制袋宽度 bag width |
80-250mm |
100-340mm |
|
插边尺寸 gusset width |
20-110mm |
20-90mm |
|
梯口高度 bag mouth height |
15mm-18mm |
15/20mm |
|
纸料厚度 material thickness |
45-80gsm |
45-80gsm |
|
纸卷宽度 scroll width |
160-780mm |
220-1000mm |
|
纸料直径 scroll diameter |
1000mm |
1000mm |
|
纸芯内径 scroll core diameter |
76mm |
76mm |
|
薄膜宽度 rolling film width |
50-180mm |
50-200mm |
|
薄膜厚度 film thickness |
0.02-0.035mm(OPP,PET) |
0.02-0.035mm(OPP,PET) |
|
薄膜直径 rolling film diameter |
500mm |
500mm |
|
薄膜内径 rolling film core diameter |
76mm |
76mm |
|
总功率 power supply |
380v 3phase 12kw |
380v 3phase 15kw |
|
工作气源 air pressure supply |
≥0.12m³/min,0.5-0.8MPA |
≥0.12m³/min, 0.5-0.8MPA |
|
整机重量 machine weight |
3500kgs |
4500kgs |
|
整机尺寸 machine size |
6000*1600*1800mm |
9100*1900*1950mm |
